ASTM B111 C71500 O61 COPPER NICKEL ALLOY SEAMLESS TUBE FOR CONDENSER

Name: ASTM B111 C71500 O61 COPPER NICKEL ALLOY SEAMLESS TUBE FOR CONDENSER
Brand: YUHONG
Price: 1 USD

Quality ASTM B111 C71500 O61 COPPER NICKEL ALLOY SEAMLESS TUBE FOR CONDENSER wholesale

Brand Name : YUHONG

Model Number : B111/SB111 C71500

Certification : ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008

Place of Origin : CHINA

MOQ : 500KG

Price : Negotiable

Payment Terms : L/C AT SIGHT, T/T

Supply Ability : 100 TONS PER MONTH

Delivery Time : Depends on Quantity

Packaging Details : Ply-wooden Case /Iron Case/ Bundle With Plastic Cap

Product Name : Copper Nickel Alloy SMLS Tube

Steel Grade : SB111/B111 C71500

Type : Seamless

Application : Condenser / Air Cooler

Length : Single random length, double random length or as customer's actual request

Alloy or not : Copper Nickel Alloy

Contact Now

ASTM B111/ASME SB111 C71500 O61 COPPER NICKEL ALLOY TUBE FOR CONDENSER

We are one of the biggest manufactures of stainless steel & duplex steel & alloy steel tubes and pipes in China. With development more than 20 years, we have accumulated a great many clients all around the world and Yuhong products also won the great praise among the customers.

C70600 (C706) & C71500 (C715), Copper nickel offers excellent corrosion resistance, especially in marine salt water environments. The main, wrought copper-nickel alloys chosen for sea water service contain 10 or 30 percent nickel. They also have important additions of iron and manganese which are necessary to maintain good corrosion resistance. Some of the primary uses for C706 include copper nickel fittings (CuNi Fittings) as well as condensers and exchanger shells.

Overview

Copper Nickel alloy Tube has extremely well resistance to biofouling and marine corrosion, and possess good fabricability. Copper gains more strength and corrosion resistance when nickel is added to it. UNS C71500 copper nickel alloy has medium high strength and good creep resistance at high temperatures. This alloy is expensive in comparison with copper-aluminum alloys and other alloys with similar mechanical properties. C71500 copper-nickel is an alloy of copper, further classified as a copper-nickel . CW354H is the EN numeric designation for this material. C71500 is the UNS number. Additionally, the EN chemical designation is CuNi30Mn1Fe. The British Standard (BS) designation is CN107. And the industry name is Cupronickel 70/30.

Specification

ASTM B111/B111M Standard Specification for Copper and Copper-Alloy Seamless Condenser Tubes and Ferrule Stock.

Standard Grade	ASTM B111 C71500	EN 12451 CuNi30Mn1Fe (CW354H)	DIN 17664/1785 CuNi30Mn1Fe	BS 2871 CN107	JIS H3300 C7150	GB/T 8890 BFe30-1-1
Cu	Bal.	Bal.	Bal.	Bal.	Bal.	Bal.
Pb	0.05 max	0.02 max	0.03 max	0.01 max	0.05 max	0.02 max
Fe	0.4-1.0	0.4-1.0	0.4-1.0	0.4-1.0	0.2-1.0	0.5-1.0
Ni	29.0-33.0	30.0-32.0	30.0-32.0	30.0-32.0	29.0-33.0	29.0-32.0
Zn	1.0 max	0.5 max	0.5 max	-	0.5 max	0.3 max
S	-	0.05 max	0.06 max	0.08 max	-	0.05 max
P	-	0.02 max	-	-	-	0.06 max
Mn	1.0 max	0.5-1.5	0.5-1.5	0.5-1.5	0.2-1.0	0.5-1.2
C	-	0.05 max	0.06 max	0.06 max	-	0.05 max
Sn	-	0.05 max	-	-	-	0.03 max
Total Impurities	-	0.2 max	0.1 max	0.3 max	-	0.7 max
Condition	O61	R370	F37	M	O	M
	HR50	R480	-	O	-	Y2
	-	-	-	-	-	-
Yield Strength N/mm2	125 min	120 min	120-220	-	-	-
	345 min	300 min	-	-	-	-
	-	-	-	-	-	-
Tensile Strength N/mm2	360 min.	370 min	370 min	-	363 min	370 min
	495 min.	480 min	-	-	-	490 min
	-	480 min.	-	-	-	-
Elongation (%)	-	35 min	35 min	-	30 min	30 min
	12min. (WT<1.21 mm)	12 min	-	-	-	10 min
	15min. (WT>1,21 mm)	-	-	-	-	-
Hardness Hv5	-	-	-	150 min	-	-
	-	-	-	90-120	-	-
	-	-	-	-	-	-

C71500 Physical Properties

Properties	Metric	Imperial
Density	8.94 g/cm3	0.323 lb/in3
Melting point	1171°C	2140°F

C71500 Chemical Composition

Grade	C(Max)	Pb	Mn	P	S	Zn	Fe	Ni	Cu
C71500	0.05	0.02	1.0	0.02	0.02	0.50	0.4-1.0	29.0-33.0	Balance

Application:

Chillers
Heat Condensers & Exchangers
Power Plants
Refineries
Desalination Plants
Ship Building & Ship Repairs
High Capacity Power Plants
Distiller Tubes
Evaporators & Ferrules
