ASTM A182 F53 (S32750, 2507) , Super Duplex Steel flange, SO RF 1" CLASS 150 B16.5

Place of Origin : China

Brand Name : YUHONG

Certification : API, PED,ABS, NK, KR, DNV, LR,

MOQ : 1PC

Price : NEGITABLE

Packaging Details : PLY-WOODEN CASE

Delivery Time : 7DAYS

Payment Terms : T/T , LC

Supply Ability : 100 TONS PER MONTH

Model Number : F53, S32750, 2507

Standard : ASTM A182, ASME SA182 , Norsok L-005

Material Grade : F51, F53, F55, F44 , S31803 , S32205, S32750, S32760

NDT : PT, UT,

Flange Type : WN FLANGE , SO FLANGE, LAP JOINT FLANGE, BLIND FLANGE , ROOSE FLANGE, ORIFICE FLANGE ,THREAD FLANGE

Face Type : FF, RF, RTJ

Size : 1/8" to 98"

Pressure grade : 75 LBS to 20000 LBS

Contact Now

ASTM A182 F53 (S32750, 2507) Super Duplex Steel flange

YUHONG GROUP deal with Austenitic Stainless Steel, Nickel Alloy Steel(Hastelloy , Monel, Inconel, Incoloy ) forged flange already more than 25 years, every year we sell huge qty of flange to more than 45 countries, Like Italy, UK, Gernmany, USA, Canada, Chile, Colombia, Saudi Arabia, Korea, Singapore, Austrial, Poland, France , ....And our group branch company and factory have been already approved by :ABS, DNV, GL, BV, PED 97/23/EC, AD2000-WO, GOST9941-81, CCS, TS, CNNC, ISO9001-2008, ISO 14001-2004.

GRADE
C≤
Mn≤
Si≤
S≤
P≤
Cr≤
Ni
Mo
Cu≤
N
S32750
(2507)
00Cr25Ni7Mo4N
0.03
1.20
0.8
0.020
0.035
24.0/26.0
6.0/8.0
3.0/5.0
0.50
0.24/0.32

Mechanical Properties Of ASTM A182 F53 Flanges
Alloy Tensile Strength ksi Proof Strength 0.2% ksi (min) Elongation (%) (min) Hardness Rockwell C
Super Duplex F53 Annealed Condition 110-135 80 15 28 max

  • ASTM A182 F53 (S32750, 2507) , Super Duplex Steel flange, SO RF 1" CLASS 150 B16.5

  • STANDARD SPECIFICATIONS OF SLIP ON FLANGE:

  • Type: Slip on Flange (SO / SO RF / SO FF )

  • Size: ½” (15 NB) to 48″ (1200NB)

  • Class: 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc.

  • DIN: DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673

  • BS: BS4504 , BS4504, BS1560, BS10

  • Type: SO RF, WN RF, BL RF, SW RF, LAP Joint, Threaded, Reducing, Spectacle, etc.

  • Specialize As per drawing

  • Standard: ANSI B16.5, ANSI B16.47, ANSI B16.36, ANSI B16.48, BS 4504, EN1092, UNI 2277/2278, DIN, JIS, SABS1123, GOST-12820

  • Coating/Surface Treatment :Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized

  • Connection Type: Ring Type Joint, Lap-Joint Face, Raised Face, Flat Face, Large Male-Female, Small Male-Female, Large, Tongue & Groove, Small Tongue & Groove

  • Flange Face Type: Flat Face (FF), Raise Face (RF), Ring Joint (RJT)

  • Dimensions: ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings

  • Packing :No Fumigate or Fumigate Plywood/Wood Pallet or Case

  • Application:

  • 1. Petrochemical industry

    2. Pharmaceutical industry

    3. Food industry

    4. Aviation and aerospace industry

    5. Architectural decoration industry

    6. Oil and gas industry

  • ASTM A182 F53 (S32750, 2507) , Super Duplex Steel flange, SO RF 1" CLASS 150 B16.5
